#include <component.h>

Inheritance diagram for CComponent:

Collaboration diagram for CComponent:

Public Member Functions
virtual	~CComponent ()

virtual int	Sizeof () const =0

class CGameClient *	GameClient () const

class IClient *	Client () const

virtual void	OnStateChange (int NewState, int OldState)

virtual void	OnConsoleInit ()

virtual void	OnInit ()

virtual void	OnShutdown ()

virtual void	OnReset ()

virtual void	OnWindowResize ()

virtual void	OnRefreshSkins ()

virtual void	OnRender ()

virtual void	OnNewSnapshot ()

virtual void	OnRelease ()

virtual void	OnMapLoad ()

virtual void	OnMessage (int Msg, void *pRawMsg)

virtual bool	OnCursorMove (float x, float y, IInput::ECursorType CursorType)

virtual bool	OnInput (const IInput::CEvent &Event)

Protected Member Functions
class IKernel *	Kernel () const

class IEngine *	Engine () const

class IGraphics *	Graphics () const

class ITextRender *	TextRender () const

class IInput *	Input () const

class IStorage *	Storage () const

class CUi *	Ui () const

class ISound *	Sound () const

class CRenderTools *	RenderTools () const

class IConfigManager *	ConfigManager () const

class CConfig *	Config () const

class IConsole *	Console () const

class IDemoPlayer *	DemoPlayer () const

class IDemoRecorder *	DemoRecorder (int Recorder) const

class IFavorites *	Favorites () const

class IServerBrowser *	ServerBrowser () const

class CLayers *	Layers () const

class CCollision *	Collision () const

int64_t	time () const

float	LocalTime () const

class IHttp *	Http () const

Protected Attributes
CGameClient *	m_pClient

Friends
class	CGameClient

Detailed Description

This class is inherited by all the client components.

These components can implement the virtual methods such as OnInit(), OnMessage(int Msg, void *pRawMsg) to provide their functionality.

Constructor & Destructor Documentation

◆ ~CComponent()

virtual CComponent::~CComponent ( )

inlinevirtual

The component virtual destructor.

Member Function Documentation

◆ Client()

class IClient * CComponent::Client ( ) const

Get the client interface.

◆ Collision()

class CCollision * CComponent::Collision ( ) const

protected

Get the collision interface.

◆ Config()

class CConfig * CComponent::Config ( ) const

protected

Get the config interface.

◆ ConfigManager()

class IConfigManager * CComponent::ConfigManager ( ) const

protected

Get the config manager interface.

◆ Console()

class IConsole * CComponent::Console ( ) const

protected

Get the console interface.

◆ DemoPlayer()

class IDemoPlayer * CComponent::DemoPlayer ( ) const

protected

Get the demo player interface.

◆ DemoRecorder()

class IDemoRecorder * CComponent::DemoRecorder ( int Recorder ) const

protected

Get the demo recorder interface.

Parameters

Recorder A member of the RECORDER_x enum

See also: RECORDER_MANUAL; RECORDER_AUTO; RECORDER_RACE; RECORDER_REPLAYS

◆ Engine()

class IEngine * CComponent::Engine ( ) const

protected

◆ Favorites()

class IFavorites * CComponent::Favorites ( ) const

protected

◆ GameClient()

class CGameClient * CComponent::GameClient ( ) const

inline

Get a pointer to the game client.

◆ Graphics()

class IGraphics * CComponent::Graphics ( ) const

protected

Get the graphics interface.

◆ Http()

class IHttp * CComponent::Http ( ) const

protected

Get the http interface

◆ Input()

class IInput * CComponent::Input ( ) const

protected

Get the input interface.

◆ Kernel()

class IKernel * CComponent::Kernel ( ) const

protected

Get the kernel interface.

◆ Layers()

class CLayers * CComponent::Layers ( ) const

protected

Get the layers interface.

◆ LocalTime()

float CComponent::LocalTime ( ) const

protected

Gets the local time.

◆ OnConsoleInit()

virtual void CComponent::OnConsoleInit ( )

inlinevirtual

Called to let the components register their console commands.

Reimplemented in CBinds, CCamera, CChat, CGameConsole, CControls, CEmoticon, CGhost, CMenus, CScoreboard, CSpectator, CStatboard, and CVoting.

◆ OnCursorMove()

virtual bool CComponent::OnCursorMove	(	float	x,
		float	y,
		IInput::ECursorType	CursorType
	)

inlinevirtual

Called on mouse movement, where the x and y values are deltas.

Parameters

x	The amount of change in the x coordinate since the last call.
y	The amount of change in the y coordinate since the last call.
CursorType	The type of cursor that caused the movement.

Reimplemented in CControls, CEmoticon, CMenus, and CSpectator.

◆ OnInit()

virtual void CComponent::OnInit ( )

inlinevirtual

Called to let the components run initialization code.

Reimplemented in CBackground, CChat, CGameConsole, CCountryFlags, CDamageInd, CHud, CInfoMessages, CItems, CMapImages, CMapLayers, CMenuBackground, CMenus, CNamePlates, CParticles, CPlayers, CSkins, CSkins7, and CSounds.

◆ OnInput()

virtual bool CComponent::OnInput ( const IInput::CEvent & Event )

inlinevirtual

Called on a input event.

Parameters

Event The input event.

Reimplemented in CBinds::CBindsSpecial, CBinds, CChat, CGameConsole, CEmoticon, CMenusKeyBinder, CMenus, CMotd, and CSpectator.

◆ OnMapLoad()

virtual void CComponent::OnMapLoad ( )

inlinevirtual

Called on map load.

Reimplemented in CBackground, CGhost, CMapImages, CMapLayers, CMapSounds, CMenuBackground, and CRaceDemo.

◆ OnMessage()

virtual void CComponent::OnMessage	(	int	Msg,
		void *	pRawMsg
	)

inlinevirtual

Called when receiving a network message.

Parameters

Msg	The message type.
pRawMsg	The message data.

See also: NETMSGTYPE_SV_DDRACETIME; CNetMsg_Sv_DDRaceTime

Reimplemented in CBroadcast, CChat, CGameConsole, CControls, CGhost, CHud, CInfoMessages, CMotd, CRaceDemo, CScoreboard, CStatboard, and CVoting.

◆ OnNewSnapshot()

virtual void CComponent::OnNewSnapshot ( )

inlinevirtual

Called when a new snapshot is received.

Reimplemented in CGhost, CHud, and CRaceDemo.

◆ OnRefreshSkins()

virtual void CComponent::OnRefreshSkins ( )

inlinevirtual

Called when skins have been invalidated and must be updated.

Reimplemented in CChat, CGhost, CInfoMessages, and CMenus.

◆ OnRelease()

virtual void CComponent::OnRelease ( )

inlinevirtual

Called when the input gets released, for example when a text box loses focus.

Reimplemented in CChat, CEmoticon, CScoreboard, CSpectator, and CStatboard.

◆ OnRender()

virtual void CComponent::OnRender ( )

inlinevirtual

Called when the component should get rendered.

The render order depends on the component insertion order.

Reimplemented in CBackground, CBroadcast, CCamera, CChat, CGameConsole, CControls, CDamageInd, CDebugHud, CEffects, CEmoticon, CFreezeBars, CGhost, CHud, CInfoMessages, CItems, CMapLayers, CMapSounds, CMenuBackground, CMenus, CMotd, CNamePlates, CParticles, CParticles::CRenderGroup< TGROUP >, CParticles::CRenderGroup< GROUP_PROJECTILE_TRAIL >, CParticles::CRenderGroup< GROUP_TRAIL_EXTRA >, CParticles::CRenderGroup< GROUP_EXPLOSIONS >, CParticles::CRenderGroup< GROUP_EXTRA >, CParticles::CRenderGroup< GROUP_GENERAL >, CPlayers, CScoreboard, CSounds, CSpectator, CStatboard, and CTooltips.

◆ OnReset()

virtual void CComponent::OnReset ( )

inlinevirtual

Called to reset the component. This method is usually called on your component constructor to avoid code duplication.

See also: CHud::CHud(); CHud::OnReset()

Reimplemented in CBroadcast, CCamera, CGameConsole, CControls, CDamageInd, CEmoticon, CGhost, CHud, CInfoMessages, CMenus, CParticles, CRaceDemo, CScoreboard, CSounds, CSpectator, CStatboard, CTooltips, and CVoting.

◆ OnShutdown()

virtual void CComponent::OnShutdown ( )

inlinevirtual

Called to cleanup the component. This method is called when the client is closed.

Reimplemented in CGhost, CMenus, CRaceDemo, and CSkins.

◆ OnStateChange()

virtual void CComponent::OnStateChange	(	int	NewState,
		int	OldState
	)

inlinevirtual

This method is called when the client changes state, e.g from offline to online.

See also: IClient::STATE_CONNECTING; IClient::STATE_LOADING; IClient::STATE_ONLINE

Reimplemented in CChat, CGameConsole, CMapSounds, CMenus, CMotd, CRaceDemo, and CSounds.

◆ OnWindowResize()

virtual void CComponent::OnWindowResize ( )

inlinevirtual

Called when the window has been resized.

Reimplemented in CBroadcast, CChat, CHud, CInfoMessages, CMenus, CMotd, and CNamePlates.

◆ RenderTools()

class CRenderTools * CComponent::RenderTools ( ) const

protected

Get the render tools interface.

◆ ServerBrowser()

class IServerBrowser * CComponent::ServerBrowser ( ) const

protected

Get the server browser interface.

◆ Sizeof()

virtual int CComponent::Sizeof ( ) const

pure virtual

Gets the size of the non-abstract component.

Implemented in CBackground, CBinds, CBinds::CBindsSpecial, CBroadcast, CCamera, CChat, CGameConsole, CControls, CCountryFlags, CDamageInd, CDebugHud, CEffects, CEmoticon, CFlow, CFreezeBars, CGhost, CHud, CInfoMessages, CItems, CMapImages, CMapLayers, CMapSounds, CMenuBackground, CMenusKeyBinder, CMenus, CMotd, CNamePlates, CParticles, CParticles::CRenderGroup< TGROUP >, CParticles::CRenderGroup< GROUP_PROJECTILE_TRAIL >, CParticles::CRenderGroup< GROUP_TRAIL_EXTRA >, CParticles::CRenderGroup< GROUP_EXPLOSIONS >, CParticles::CRenderGroup< GROUP_EXTRA >, CParticles::CRenderGroup< GROUP_GENERAL >, CPlayers, CRaceDemo, CScoreboard, CSkins, CSkins7, CSounds, CSpectator, CStatboard, CTooltips, and CVoting.

◆ Sound()

class ISound * CComponent::Sound ( ) const

protected

Get the sound interface.

◆ Storage()

class IStorage * CComponent::Storage ( ) const

protected

Get the storage interface.

◆ TextRender()

class ITextRender * CComponent::TextRender ( ) const

protected

Get the text rendering interface.

◆ time()

int64_t CComponent::time ( ) const

protected

Gets the current time.

See also: time_get()

◆ Ui()

class CUi * CComponent::Ui ( ) const

protected

Get the ui interface.

Friends And Related Function Documentation

◆ CGameClient

friend class CGameClient

friend

Member Data Documentation

◆ m_pClient

CGameClient* CComponent::m_pClient

protected

The documentation for this class was generated from the following files:

src/game/client/component.h
src/game/client/component.cpp
